| Capacity | Ton | 100 |
| Overall Height | A(mm) | 2070 |
| Working Width | B(mm) | 1150 |
| Frame Width | C(mm) | 1505 |
| Overall Width | D(mm) | 1,745 |
| Working Width of Side | E(mm) | 455 |
| Frame Width of Side | F(mm) | 510 |
| Overall Width of Side | G(mm) | 1150 |
| Frame Hole | H(mm) | 52 |
| Distance Between Frame Hole | I(mm) | 133 |
| Piston Rod Diameter | J(mm) | 98 |
| Ram Stroke | K(mm) | 235 |
| Working Height Ram to Table | L(mm) | 835 |
| Weight | Kg | 1270 |
