Specification
ST-Code : I03-0006
Model : ST3800
Type : SSingle Phase
Frequency : 50 Hz.
Maximum power ouput : 3.0KW.
Rated power output : 2.5KW.
Voltage(AC) : 220V.
Engine : 7HP
Speed : 4000 RPM.
Voltage(DC) : 12V.
Electric current(DC) : 8.3A
Power factors cos : 0.8
Stable voltage adjustment rate : 1%
no loading wave changing rate : 3%
Linear load waveforms change rate : 5%
Ability to load the asynchronous : 0.75%
With UPS for nonlinear loads ability : 80%
Insulation class : F
Noise(7m) : 66 dB (A)
Petrol : Gasoline
Type : –
Model :1-cylinder, 4-stroke, air-cooled gasoline engine
Continue : 3.0KW.
Max. power output : 2.8KW.
Bore *stroke : 86*72MM
Volume : 210cm3
Cooling system : Air-cooled
Lubricate system : T.C.I
Lubrication oil volume : 0.6L
Starting system : Recoil/Electric
Fuel oil : Gasoline Petrol
Fuel capacity : 15L
Low oil pressure protection : 0.7MPa
Total weight : 44 kgs
Overall dimension : 60.5*44*43.5mm
